Villeroy & Boch Architectura 3.0 DirectFlush Wall Hung Toilet Pan and Seat Alpine White
Villeroy & Boch Architectura 3.0 DirectFlush Wall Hung Toilet Pan and Seat Alpine White
Villeroy & Boch Architectura 3.0 DirectFlush Wall Hung Toilet Pan and Seat Alpine White
Villeroy & Boch Architectura 3.0 DirectFlush Wall Hung Toilet Pan and Seat Alpine White
Based on 2878 reviews
90%
(2595)
4%
(121)
1%
(43)
1%
(31)
3%
(88)
Villeroy & Boch

Villeroy & Boch Architectura 3.0 DirectFlush Wall Hung Toilet Pan and Seat Alpine White

SKU 4694HR01S4B

Optional flush button upgrade

Please select
$799 $739

Estimate Delivery

  • Usually dispatches in 3-6 business days

Available with standard or slim soft close seat, the Architectura 3.0 exudes European elegance with smooth sides and a minimalist design that is reinforced by the matching ViConnect concealed cistern. Required: In-Wall Hung Cistern + Flush Plate. Recommended Products: ViConnect Cistern and Frame 92233500 or 92233600, with matching E100 E200 or E300 Flush Plates. Product Details. SKU: 4694HR01S4B  Brand: Villeroy & Boch  Range: Architectura  Colour: Alpine White  Warranty: 10 Years (conditions apply)  Seat: Soft Closing / Quick Release

Read more
Free Shipping On Orders $100+
Free Shipping On Orders $100+
Reputable Brand
Reputable Brand
Over 2200 happy customers
Over 2200 happy customers
View specifications

Available with standard or slim soft close seat, the Architectura 3.0 exudes European elegance with smooth sides and a minimalist design that is reinforced by the matching ViConnect concealed cistern.

Required: In-Wall Hung Cistern + Flush Plate

Recommended Products: ViConnect Cistern and Frame 92233500 or 92233600, with matching E100 E200 or E300 Flush Plates

Product Details

  • SKU: 4694HR01S4B
  • Brand: Villeroy & Boch
  • Range: Architectura
  • Colour: Alpine White
  • Warranty: 10 Years (conditions apply)
  • Seat: Soft Closing / Quick Release
  • Trap: P Trap
  • Flush Type: DirectFlush
  • WELS Rating: 4 Star
  • Water Consumption: 4.5/3L (3.5 Avg) Flush
Brand:
Villeroy & Boch
SKU:
4694HR01S4B

Free Delivery on orders over $100 (excluding toilets & baths)

Shipping policy

Choosing a toilet might not be glamorous, but getting it right makes a big difference to comfort, cleaning, and how your bathroom looks. Here's what to think about.

1. Measure your space carefully

Measure from the wall to your existing waste outlet (the centre of the pipe) – this is your "set-out" distance, usually 90mm, 120mm or 150mm in Australia. Also measure how much space you have side-to-side and front-to-back, especially if it's a small bathroom. You need enough room to sit comfortably and open the door.

2. Choose your toilet style

  • Back-to-wall toilets: Sit flush against the wall with a concealed cistern for a sleek, modern look that's easier to clean around.
  • Wall-hung toilets: Mount to the wall with the cistern hidden inside – looks minimal, saves floor space, and makes cleaning underneath easy.
  • Close-coupled toilets: The cistern sits directly on the pan – practical, affordable, and easy to install or replace.

3. Pick a flushing system

Look for a dual-flush system (3L/4.5L or similar) to save water. Some toilets also have rimless or special flushing technology that cleans better and stays hygienic longer, which is worth considering if you want less scrubbing.

4. Match the style to your bathroom

White toilets are classic and suit any style. Soft-close seats are quieter and feel nicer. If you're going modern or minimal, a wall-hung or back-to-wall design looks cleaner. Traditional bathrooms work well with close-coupled suites.

6. Consider smart features

Want extra features? Smart toilets and bidet toilets offer built-in washing, heated seats, and more – perfect if you're after extra comfort and hygiene.

7. Don't forget the flush button

Your toilet flush button is part of the look, especially for in-wall cisterns. Choose a finish that matches your tapware and accessories.

8. Set your budget

Basic close-coupled toilets start around $300–$600. Back-to-wall and wall-hung suites with concealed cisterns sit between $600–$1,500+, depending on brand and features. Installation costs vary depending on complexity, so chat with your plumber early.

Need help choosing?

Browse our full range of toilets and toilet suites to find the perfect fit for your bathroom. Or visit our building and renovating tips blog for practical advice, real renovation examples, and the latest bathroom design trends to help you plan with confidence.

CURATED COLLECTIONS

Explore the Villeroy & Boch Wall Hung Pans Collection

Villeroy & Boch Antao TwistFlush Wall Hung Toilet Pan and Seat Pure Black
Villeroy & Boch Antao TwistFlush Wall Hung Toilet Pan and Seat Almond
Villeroy & Boch Subway 3.0 TwistFlush Wall Hung Toilet Pan and Slim Seat CeramicPlus Alpine White
Villeroy & Boch Subway 3.0 TwistFlush Wall Hung Toilet Pan and Slim Seat Alpine White
Villeroy & Boch Subway 3.0 TwistFlush Wall Hung Toilet Pan and Seat Stone White
Villeroy & Boch Subway 3.0 TwistFlush Wall Hung Toilet Pan and Seat CeramicPlus Alpine White
View Entire Collection
Premium features

Where design meets function

Architectura Range

The Architectura range by Villeroy & Boch brings timeless elegance to bathroom design with its calming geometric forms and adaptable options. Create a space that reflects your personal style with versatile designs choices. With refined practicality, advanced hygiene features and impressive value, Architectura creates a bathroom that feels thoughtfully designed and effortlessly sophisticated.

Architectura 3.0 DirectFlush Wall Hung Toilet Pan and Seat

The Architectura 3.0 Wall Hung Toilet introduces a clean architectural look, defined by its rounded contours, smooth sides and compact form that suspends gracefully from the floor. Made from high quality ceramic, it keeps its refined appearance with a surface that helps reduce dirt and bacteria buildup.

Comfort in Motion

The standard soft close seat gives you steady support and a gentle, quiet closing motion that enhances daily comfort. Its quick release design helps you maintain a fresh bathroom with ease. DirectFlush technology provides full and efficient rinsing for excellent hygiene. With a P trap configuration and a wall hung layout that opens up the floor area, your bathroom feels more spacious, organised and modern.
